Sand And Gravel Pump
The G (GH) serie sand and gravel pump is a single-stage, single suction, cantilever, horizontal, centrifugal slurry pump, mainly used for conveying strong abrasive particles that are too big for general slurry pump to transport, such as granular coal, metal smelting slag and root crops, as well as for dredger, river dredging, mining and other fields. The pump is especially suitable for large flow quantity, high concentration, high head working conditions, and for transporting high temperature strong abrasive slurry owing to its excellent cavitation resistance and abrasion resistance.
G (GH) Type Industrial Slurry Pump Manufacturers High Pressure Sand And Gravel Pump.
The sand and gravel pump consists of a pump head, sealing components, bearing components, brackets, etc. The bearing lubrication method is grease lubrication.
Scope of use:
Suitable for conveying strong corrosion and high concentration slag slurry in industrial sectors such as metallurgy, mining, coal, power building materials, etc. The sand and gravel pump can also be used in multi-stage series connection.
Structural diagram:
1. Axis
2. Bracket
3. Impeller disassembly ring
4. Positioning sleeve
5. Sealing components
6. Splicing board
7. Rear guard plate
8. Pump body
9. Cartridge
10. Pump cover
11. Front protective panel
12. Impeller 13. Split flange
Performance Parameter
Model | Capacity Q(m3/h) | Head (m) | Speed n(r/min) | NPSHr (m) | Efficieney η(%) | Weight (kg) | Overall dimensions L×W×H (mm) | Dia.of pump (mm) | |
| Inlet | Outlet | ||||||||
| 6/4D-G | 36.00 108.00 180.00 | "9.00 8.20 7.00" | 600 | 2 | 55 | 460 | 1006×500×673 | 150 | 100 |
| 6/4D-G | 50.40 122.40 187.20 | 12.50 12.00 10.00 | 700 | 2.2 | 54 | 460 | 1006×500×673 | 150 | 100 |
| 6/4D-G | 57.60 129.60 194.40 | 16.40 15.50 14.00 | 800 | 2.5 | 55 | 460 | 1006×500×673 | 150 | 100 |
| 6/4D-G | 72.00 144.00 208.80 | 20.50 20.00 18.00 | 900 | 2.7 | 55 | 460 | 1006×500×673 | 150 | 100 |
| 6/4D-G | 79.20 151.20 216.00 | 24.00 23.50 22.00 | 980 | 2.8 | 58 | 460 | 1006×500×673 | 150 | 100 |
| 6/4D-G | 79.20 151.20 216.00 | 25.00 24.50 23.00 | 1000 | 2.5 | 57 | 460 | 1006×500×673 | 150 | 100 |
| 6/4D-G | 93.60 162.00 230.40 | 31.00 30.00 28.00 | 1100 | 2.7 | 56 | 460 | 1006×500×673 | 150 | 100 |
| 6/4D-G | 100.80 165.60 237.60 | 36.80 36.00 34.00 | 1200 | 3 | 55 | 460 | 1006×500×673 | 150 | 100 |
| 6/4D-G | 108.00 180.00 244.80 | 44.00 43.00 40.00 | 1300 | 3.2 | 53 | 460 | 1006×500×673 | 150 | 100 |
| 6/4D-G | 72.00 129.60 187.20 | 51.00 50.60 49.50 | 1400 | 3.5 | 52 | 460 | 1006×500×673 | 150 | 100 |
| 8/6E-G | "133.20 252 360" | "15 13 10" | 800 | 2.5 | 60 | 1120 | 1286×550×862 | 200 | 150 |
| 8/6E-G | "133.2 288 396" | "19 18.5 13.5" | 900 | 2.5 | 60 | 1120 | 1286×550×862 | 200 | 150 |
| 8/6E-G | "136.8 288 414" | "22.5 19.5 16" | 980 | 2.7 | 60 | 1120 | 1286×550×862 | 200 | 150 |
| 8/6E-G | "144 288 424.8" | "24 20.90 16.50" | 1000 | 3 | 59 | 1120 | 1286×550×862 | 200 | 150 |
| 8/6E-G | "144 324 468" | "30 25.5 20.5" | 1100 | 3 | 58 | 1120 | 1286×550×862 | 200 | 150 |
| 8/6E-G | "165.6 342 504" | "36 30.9 24.3" | 1200 | 3 | 57 | 1120 | 1286×550×862 | 200 | 150 |
| 8/6E-G | "187.2 378 540" | "42 36 29" | 1300 | 3.2 | 57 | 1120 | 1286×550×862 | 200 | 150 |
| 8/6E-G | "216 396 576" | "48.2 42 33.5" | 1400 | 3.5 | 57 | 1120 | 1286×550×862 | 200 | 150 |
| 10/8F-G | 216.00 652.80 489.60 | 12.50 12.00 10.80 | 500 | 3 | 60 | 2250 | 1591×857×1143 | 250 | 200 |
| 10/8F-G | 244.80 432.00 594.00 | 18.00 17.10 15.50 | 600 | 3 | 60 | 2250 | 1591×857×1143 | 250 | 200 |
| 10/8F-G | 254.00 434.60 635.00 | 21.40 20.40 18.40 | 650 | 3 | 60 | 2250 | 1591×857×1143 | 250 | 200 |
| 10/8F-G | 237.60 468.00 684.00 | 21.80 23.70 21.40 | 700 | 3 | 60 | 2250 | 1591×857×1143 | 250 | 200 |
| 10/8F-G | 306.00 540.00 792.00 | 32.00 31.00 28.00 | 800 | 2.8 | 59 | 2250 | 1591×857×1143 | 250 | 200 |
| 10/8F-G | 329.80 578.00 833.00 | 36.10 35.00 31.00 | 850 | 3.5 | 61 | 2250 | 1591×857×1143 | 250 | 200 |
| 10/8F-G | 349.20 612.00 882.00 | 40.50 39.20 34.80 | 900 | 3.7 | 60 | 2250 | 1591x857×1143 | 250 | 200 |
| 10/8F-G | 382.20 650.00 930.60 | 44.20 42.40 37.70 | 940 | 6 | 63 | 2250 | 1591×857×1143 | 250 | 200 |
| 10/8S-G | 216.00 352.80 489.60 | 12.50 12.00 10.80 | 500 | 3 | 60 | 2285 | 1720×950×983 | 250 | 200 |
| 10/8S-G | 254.00 434.60 635.00 | 21.40 20.40 18.40 | 650 | 3 | 60 | 2285 | 1720×950×983 | 250 | 200 |
|
|
